1999 DAEWOO DMV 500 CNC VERTICAL MACHINING CENTER

Description

Table Size ............. 47.2" x 19.7"
Max Table Load. . 1,764 Lbs
X Axis Travel ...................... 40"
Y Axis Travel. ................... 19.7"
Z Axis Travel..................... 20.1"
Spindle Nose to Table Top ...............................5.9" - 26"
Spindle Speeds.. 40 - 8,000 RPM
Spindle taper.................. CT40
Spindle Motor . 20/15 HP
Tool Changer ....... 30 Side Mount
Rapid Traverse Rates .................. 1,181X,Y/ 945Z IPM
Cutting Feed Rates ...... 760 IPM
Machine weight...... 16,700 Lbs
Machine Dimensions .............. 123"L x 96"W x 110"H

Equipped With:
Fanuc 18M CNC Control
Heavy Box Way Construction
Rigid Tapping
Chip Conveyor
Full Enclosure
Coolant Tank & Pump
ROTARY TABLE NOT INCLUDED
Location: Detroit, MI
